Linear technology
applications
Built for real-world performance
01
backstop
Utilize IM Series Power Beam to provide rugged, programmable backstop positioning. Equipped with integral bearing support and enclosed protection to ensure repeatable accuracy in demanding environments.
02
cut to length
IA Series Power Beam delivers fast, repeatable material positioning across long strokes, using encoder integration and adjustable deceleration to ensure accurate cuts and smooth stopping.
03
dip transfer
For controlled dip transfer between treatment baths, IA Series Power Beam offers precise speed control and deceleration. Its sealed enclosure protects the unit from harsh or corrosive materials to maximize longevity.
04
doors
IA Series Power Beam is the superior choice for controlled door operation. Pneumatic technology supports quick, smooth movements and endless repetitions, protected by long end-of-stroke cushioning.
05
elevate
Pneumatic-driven IA Series Power Beam delivers compact vertical lifting with load guidance, supporting heavy loads while maintaining smooth positioning without the need for external guide structures.
06
large lift
Two IM Series Power Beams paired with a common shaft enable synchronized lifting performance. Linear guides and reliable motor-driven technology ensure proper load support.
07
Load transfer
Carrying a load on linear guides, two IM Series Powerbeams can work together to transfer loads, with one unit driving and the other linked through a common shaft.
08
mix
IA Series Power Beam provides a self-supporting, rugged mount for mixing heads. Pneumatic operation delivers optimal power and depth while offering fully-enclosed, durable load support.
09
destack
IA Series Power Beam enables high-speed bottom-feed destacking, benefitting from long end-of-stroke cushioning to transfer loads at high speeds without shock.
10
pick & place
IM Series Power Beams use motor-driven technology to create a rugged, self-supporting pick-and-place system. Multi-axis functionality and repeatable positioning simplify industrial processes.
11
Reach
Pneumatic IA Series Power Beam supports “overhung” tooling for high moment capability due to enclosed, heavy-duty linear guide support. The inverted mount and purge port are beneficial for industrial environments.
12
rinse
Repeatable linear movement for industrial rinsing and cleaning applications is achieved with IA Series Power Beam. Its pneumatic drive and enclosed housing are ideal for wet areas where electrical systems may be unsuitable.
13
spray
IA Series Power Beam delivers consistent carriage velocity for even coating coverage in spray applications. Programmable positioning is possible with encoder integration, while the enclosed housing reduces ignition risk in solvent-heavy environments.
Have something else in mind?
Power Beam is equipped to engineer custom linear motion systems tailored to your unique specifications.
